Avanza All New 1.3 Manual : 1300cc Specification

2012 avanza specificationAvanza All New 1.3 : 1300cc Specification






--------------------------------All New 1.3 E M/T ----------All New 1.3 G M/T


Machine
Machine SerialK3-VEK3-VE
Engine TypeIL, 4 Cyl, 16 V, DOHC, VVT-iIL, 4 Cyl, 16 V, DOHC, VVT-i
Displacement (cc)1,2981,298
Bore X Stroke (mm)72.0 x 79.772.0 x 79.7
Maximum Output (Ps/rpm)92/6,00092/6,000
Maximum Torque (Kgm/rpm)11,9/4,40011,9/4,400
Fuel SystemEFIEFI
FuelUnleaded GasolineUnleaded Gasoline
Fuel Capacity (liter)4545
Steering (Power Steering)with (Electric Power Steering)with (Electric Power Steering)

Chassis
Wheel Drive SystemRWDRWD

Transmission
5 speed M/T5 speed M/T
Gear Ratio 1st3.7693.769
Gear Ratio 2nd2.0452.045
Gear Ratio 3rd1.3761.376
Gear Ratio 4th1.0001.000
Gear Ratio 5th--
Gear Ratio 6th--
Gear Ratio Reverse4.1284.128
Gear Ratio Final5.1255.125
Front SuspensionMacpherson Strut with Coil SpringMacpherson Strut with Coil Spring
Rear Suspension4 Link w/ Lateral Rod with Coil Spring4 Link w/ Lateral Rod with Coil Spring
Front BrakeDiscDisc
Rear BrakeDrumDrum
Sistem Rem / Additional Brake System--
Steering GearRack & PinionRack & Pinion
Tires Size185/65 R14185/65 R14

Dimension
Overall Length4.1404.140
Overall Width1.6601.660
Overall Height1.6951.695
Wheelbase 2.6552.655
Tread (Front)1.4251.425
Tread (Rear)1.4351.435
Ground Clearance 200200
Turning Radius4.74.7
Curb Weight --



















Link
source : TAM
